va-Q-shield VIP C

va-Q-shield VIP C is a microporous vacuum insulation board based on
fumed silica, which is additionally equipped with a special protective
cover of fireproof fabric, which results in even higher fire resistance. It
is characterized by smooth edges and corners due to the patented foil
folding technology (va-Q-seam®), which means that individual elements
can be joined together without joints. The va-Q-shield VIP C is manufactured climate neutrally in Germany according to strict environmental standards as per DIN EN ISO 14021. In general, rectangular panels are produced but various shapes (trapeze, triangle, corner section) are possible on request.

Advantages of va-Q-shield VIP C

  • Thermal conductivity (λ10 °C): ≤ 0.0043 W/mK (expected design value incl. aging and edge effects: 0.007 W/mK)
  • Low insulation thickness increases the usable area
  • More safety through outstanding fire protection certified with B-s1, d0 according to EN 13501-1
  • Durable insulation performance
  • Sustainable product: manufactured according to the highest quality and environmental standards (DIN EN ISO 14021)
  • Climate neutral production in Germany

Properties of va-Q-shield VIP C


Details : Enhanced usable room area due to thinner insulation material
Smooth edges and no foil overlaps due to patented va-Q-seam technology
Various standard sizes on stock
fire protection class B-s1, d0 according to EN 13501-1
Long lifetime due to optimized panel design
100 % quality control with the patented gas pressure measurement system (va-Q-check)
Sustainable product (recyclable core material)

Color : light grey

Density : [kg/m³]

temperature resistance : -75 – 80 °C (temporary up to 120 °C)

Internal gas pressure at delivery : ≤ 5 mbar (at delivery)

heat transfer coefficient (U-Wert) : 0,22 W/(m²∙K) (d = 20 mm) [W/(m²*K)]
