va-Q-pur is a microporous insulation based on a 100 % open-cell polyurethane foam, which is exclusively provided
to va-Q-tec. In general va-Q-pur is produced in rectangular shapes by our innovative va-Q-seam technique but
various shapes are possible on request. Because of the low weight core material, va-Q-pur elements are mainly
used for applications in containers but also in water boilers, refrigerators etc. va-Q-pur can be used in combination
with conventional polyurethane systems, as the higher temperature in the lathering process does not lead to a
degradation of the thermal and mechanical properties of the panels. Hereby the huge deformation resistance and
quality of the surface are the crucial points.

Properties of va-Q-pur


Details : Huge reduction of the insulation thickness compared to conventional polyurethane foams
Very high compressive strength
Low weight material
100 % quality control with the patented gas pressure measurement system (va-Q-check)

Color : silver

Density : 80 kg/m³ according to DIN EN 1602 [kg/m³]

temperature resistance : -70 – 60 °C

Internal gas pressure at delivery : < 1 mbar (at delivery)

Gas pressure rise : < 5 mbar/year (d = 15 mm)

heat transfer coefficient (U-Wert) : 0,28 W/(m²∙K) (d = 20 mm) [W/(m²*K)]

Other features

Dimensions & tolerances :

spec. heat capacity : 0,8 kJ/kgK (at room temperature) [J/kg*K]

pressure limitation : ≥ 250 kPa nach DIN EN 826 [kPa]
