va-Q-pal

The va-Q-pal is a cost efficient fully VIP-controlled pallet shipper. The high-tech solution is ideal for various purposes such as “non-return destinations”, special freight, destinations where return takes time, and for upgrading capacity for high-performance shipments. The va-Q-pal is available for shipments from -40°C to +20°C. It is very robust due to an outer carton honeycomb structure. The material can be fully recycled which underlines the green and sustainable concept of the product.

Advantages of va-Q-pal

  • Designed for door-to-door transport to remote locations
  • Two qualified performance levels with minimum payload: Standard with true 96h and more & va-Q-pal SI with true 120h and more
  • 5 qualified temperature ranges for shipments from -40 °C (without dry ice) to +20 °C available
  • PMC pallet optimized: 4 pallets with 4 va-Q-pal
  • Smooth and cost saving operation: Available as assembly kit (with intuitive design & all-season packout) or as “ready to load & go”
  • High energy efficiency enables low CO₂ emissions, product carbon footprint calculations are available
  • Ready for a second life: re-qualification with va-Q-check® and re-use of components is possible
  • Produced in a global carbon neutral company, Technology “MADE IN GERMANY”
va-Q-pal
Product Video va-Q-pal
Available in english only
Content activated

Properties of va-Q-pal

Dimensions

va-Q-pal

Payload : 1630 l

Outer dimension (L x W x H) : 56.73 x 47.72 x 61.61 inch

Inner dimension (L x W x H) : 49.29 x 40.28 x 50.12 inch

va-Q-pal SI

Payload : 1630 l

Outer dimension (L x W x H) : 56.73 x 47.72 x 61.61 inch

Inner dimension (L x W x H) : 49.29 x 40.28 x 50.12 inch

va-Q-pal +05G

ISTA 7D summer

Performance : ≥ 95 hrs

KelvinHours : ≥ 2394 Khrs

ISTA 7D winter

Performance : > 120 hrs

KelvinHours : n.a.

va-Q-pal +22G

ISTA 7D summer

Performance : ≥ 120 hrs

KelvinHours : ≥ 1176 Khrs

ISTA 7D winter

Performance : ≥ 92 hrs

KelvinHours : ≤ -1362 Khrs

va-Q-pal -21G

ISTA 7D summer

Performance : ≥ 82 hrs

KelvinHours : ≥ 4075 Khrs

va-Q-pal -26G

va-Q-tec summer

Performance : ≥ 97 hrs

KelvinHours : ≥ 4365 Khrs

va-Q-pal SI +05G

va-Q-tec summer

Performance : ≥ 132 hrs

KelvinHours : ≥ 3353 Khrs

va-Q-tec winter

Performance : ≥ 138 hrs

KelvinHours : ≤ -662 Khrs

va-Q-pal SI +22G

va-Q-tec summer

Performance : ≥ 135 hrs

KelvinHours : ≥ 1337 Khrs

va-Q-tec winter

Performance : ≥ 106 hrs

KelvinHours : ≤ -2141 Khrs

va-Q-pal SI -21G

va-Q-tec summer

Performance : ≥ 122 hrs

KelvinHours : ≥ 6137 Khrs

va-Q-pal SI -26G

va-Q-tec controlled summer

Performance : ≥ 126 hrs

KelvinHours : ≥ 5040 Khrs

va-Q-pal SI -37G

va-Q-tec controlled summer

Performance : ≥ 79 hrs

KelvinHours : ≥ 3958 Khrs
