Products for Appliances & FoodProducts for Appliances & FoodVacuum Insulation Panels va-Q-viprectangular, rigid plates as standard trapeze, triangles or corner sections as special forms Thermal conductivity λ (10°C) ≤ 0.0050 W/mK Size: 100 x 100 mm – 1000 x 600 mm Thickness: 5 – 50 mm va-Q-plusenormous flexibility Thermal conductivity λ (10°C) < 0.0035 W/mK Size: 200 x 200 mm – 1000 mm x 1900 mm va-Q-proenormous flexibility 3d panel and recesses of all kinds possible thermal conductivity λ (10°C) < 3,5 mW/mK Size: 200 x 200 mm – 1000 mm x 1900 mm Thermal packaging systems va-Q-boxSuitable for GN 1/3 and GN 2/3 trays Inner volume: 27 to 43 liters Empty weight without elements: 5,6 to 7,6 kg Temperature stability: up to 6 days va-Q-trayInternal dimensions, at the top: 540 x 342 x 93/150 mm³ Internal dimensions, at the bottom: 525 x 325 x 93/150 mm³ Inner volume: approx. 16/26 liters Temperature holding time: several hours (depending on ambient temperature and payload)
